Characteristics

 Functions

 Technical Parameters

◎ Changing frequency changing rotation speed;
◎ Small fall of rotation speed and large output torque;
◎ High measurement precision;

◎ The functions of over voltage ,overload and short circuit protection;
◎ Ten kinds of rotation speeds presetting;

◎ Constant temperature controlled;

◎ Ultra low noise;

◎ Operating position: arbitrary side of the two work sides of the test stand;

◎ Rotation speed, count and temperature are displayed in digits mode, and air pressure is displayed on the mechanical gauge.

◎ Built-in air resource.

◎ Measurement of each cylinder’s delivery at various rotation speeds;

◎ Checking of each cylinder’s injection time with static state;

◎ Checking of the mechanical speed governors;

◎ Checking of the electric magnetic valve of distributor pumps;

◎ Checking performance of the pneumatic speed governors;

◎ Checking of the pressure compensators (LDA) ;

◎ Measurement of the reflux delivery of distributor pumps; (May selection)

◎ Measurement of the internal pressure of the distributor pumps body.

◎Checking of the pneumatic speed governors’ vacuum performance; (May selection)  ◎Measurement of rack travel; ( May  selection)

◎ Checking of the sealing of fuel injection pump body .

◎Adjustable rotation speed range:0~4000r/m;

◎Double Series graduates:45cc、150cc;

◎Volume of oil tank:60L;

◎Temperature stabilization:40±20C:

◎Test oil filtering unit:5μ;

◎D.C.Supply：12v/24v;

◎Feed pressure: low:0~0.4Mpa.high:0~4Mpa;

◎Air pressure:0~0.3Mpa;

◎ 3-phase power supply: 380V/50Hz or on request;

◎ Flywheel inertia’s moment: 0.8 Kg.M2;

◎Center height: 125 mm;

◎Output power: 5.5KW、7.5KW、11KW and 15KW or on request;

◎ Overall dimensions(mm): 2370×960×1880；

◎ Net weight (KG):1200.
