Functions	Parameters	Characteristics
◎Measurement of each cylinder’s delivery at various rotation speeds; ◎Checking of each cylinder’s injection time with static state; ◎Checking of the mechanical speed governors; ◎Checking of the electromagnetic valve of distributor pumps; ◎Checking performance of the pneumatic governors; ◎ Checking of the pressure compensators (LDA) ; ◎Measurement of the reflux delivery of distributor pumps;( May  selection) ◎Measurement of the internal pressure of the distributor pumps body; ◎ Checking of the sealing of fuel injection pump body .	◎Adjustable rotation speed range:0~4000r/m; ◎Double Series graduates:45cc、150cc; ◎Volume of oil tank:60L; ◎Temperature stabilization:40±20C; ◎Test oil filtering unit:5μ; ◎D.C.Supply:12v/24v； ◎Feed pressure: low:0~0.4Mpa.high:0~4Mpa; ◎Air pressure:0~0.3Mpa; ◎ 3-phase power supply: 380V/50Hz or on request; ◎ Flywheel inertia’s moment: 0.8 KG.M2; ◎Center height: 125 mm; ◎Output power: 5.5KW、7.5KW、11KW and 15KW or on request; ◎ Overall dimensions(mm): 1650×960×1620; ◎ Net weight (KG):1200.	◎ Changing frequency changing rotation speed; ◎ Small fall of rotation speed and large output torque; ◎ High measurement precision; ◎ The functions of over voltage overload and short circuit protection; ◎ Ten kinds of rotation speeds presetting; ◎ Constant temperature controlled; ◎ Ultra low noise; ◎ Operating position: arbitrary side of the two work sides of the test stand; ◎Rotation speed, count and temperature are displayed in digits mode, and air pressure is displayed on the mechanical gauge.  ◎ Built-in air resource;
