■ Ultra large working table with three "T"type slots
■ Independent forced lubrication system
■ Rotation speed,count,temperature,rack travel,air pressure and advance angle are measured and controllde by computers in real time,then displayed by 15"LCD
■ It is very easy to find the data of the pumps in pumps database
■ Changing frequency changing rotation speed,small fall of rotation speed and large output torque
■ High precision,high efficiency and energy saving
■ Having the function of oil level display and alarm
■ Automatically generating and displaying speed characteristics curve
■ Measurement of each cylinder`s delivery at various rotation speeds
■ Checking of of each cylinder`s injection timing with static state
■ Checking of the mechanical speed governors
■ Checking of the electromagnetic valve of distributor pump
■ Checking of the pneumatic speed governors` positive pressure performance
■ Checking of the pressure compensators(LDA)
■ Measurement of the reflux delivery of distributor pump
■ Measurement of the internal pressure of the distributor pumps body
■ Checking of the pneumatic speed governors` vacuum performance
■ Measurement of rack travel
■ Checking of sealing of the fuel injection pump body
■ Measure of advance angle
■ Graduates:150/45ML
■ Oil tank volume:100L
■ Auto-controlled constant oil temperature:40±2℃
■ Test oil-filtering unit:5μ
■ D.C.supply:12V/14V
■ Feeding pressure:low:0~0.4Mpa;high:0~4Mpa
■ Pump body internal pressure:0~0.16MPa,0~1.6MPa
■ Display air pressure,range:positive:0~0.3Mpa;negative:-0.03~0Mpa
■ Speed presetting range:0-4000RPM
■ Rack travel range:0~25MM
■ Center height:125MM
■ Flywheel inertia`s moment:0.8kgm2
■ Output power:18.5KW、22KW、30KW(or on request)
■ 3-phase electrical supplies:380V/50Hz(or on request)
■ Overall dimensions:2900X840X1700(mm)
■ Net weight:1300kg
