Funtion

Parameter

Characteristic

◎Measurement of each cylinder^’s delivery at various rotation speeds;

◎Checking of each cylinder’s injection time with static state;

◎Checking of the mechanical speed governors;

◎Checking of the electromagnetic valve of distributor pumps;

◎Checking performance of the pneumatic governors;

◎ Checking of the pressure compensators (LDA) ;

◎Measurement of the reflux delivery of distributor pumps;( May  selection)

◎Measurement of the internal pressure of the distributor pumps body;

◎ Checking of the sealing of fuel injection pump body .





◎Adjustable rotation speed range:0~4000r/m;

◎Double Series graduates:45cc、150cc;

◎Volume of oil tank:60L;

◎Temperature stabilization:40±2⁰C;

◎Test oil filtering unit:5μ;

◎D.C.Supply:12v/24v；

◎Feed pressure: low:0~0.4Mpa.high:0~4Mpa;

◎Air pressure:0~0.3Mpa;

◎ 3-phase power supply: 380v/50Hz or on request;

◎ Flywheel inertia^’s moment: 0.8 KG.M²;

◎Center height: 125 mm;

◎Output power: 5.5KW、7.5KW、11KW and 15KW or on request;

◎ Overall dimensions(mm): 1650×960×1620;

◎ Net weight (KG):1200.



◎Changing frequency changing rotation speed;

◎Small fall of rotation speed and large output torque;

◎ High measurement precision;

◎ The functions of over voltage overload and short circuit protection;

◎ Ten kinds of rotation speeds presetting;

◎ Constant temperature controlled;

◎ Ultra low noise;

◎ Operating position: arbitrary side of the two work sides of the test stand;

◎ Advance angle, rotation speed, count, temperature and air pressure are displayed on 15”CRT or LCD; (May selection)

◎ Built-in air resource;
